不锈钢拉丝机

Wet 型号 S.S Wire Drawing Machine

产品介绍

It is used for drawing S.S wire from a big size to a small size
0.13mm SS wire drawing machine for cleaning ball/SS scourer

Product Application
This kind of machine is mainly used for drawing stainless steel wire, low carbon wire, galvanized iron wire, etc, the wire which can be used for clean ball.

Main feature:
1. Fully immersed lubricant system, transmission by teeth belt, constant tension, low noise, high efficiency.
2. Capstan made by special tool steel.
3. PLC control, dual motor, dual inverter, color touchscreen.
4. Special alignment device at final die position, keep wire verticality and quality, which is good for the next process.
5. Stepping motor traverse, pitch adjustable, smooth traversing.
6. Protection device for wire disorder; the machine auto stops if the mother wire disorder or break.

技术参数

Max eye mold No	20
Max inlet wire dia.	Φ0.7mm
Finish wire dia.	Φ0.1mm~Φ0.2mm
Main motor	7.5KW
Max line speed	800m/min
收线盘规格	200mm(or according to you)
排线方式	100kw Synchronous motor + flat belt
制动方式 type	Electromagnetic brake
收线电机功率	2.2Kw
Max loading	25Kw
Lubrication type	全浸式
传动方式	Flat belt
